Capacity | 100Kg |
Overall Size | 1062mm x 435mm x 366mm (L x W1 x H) |
Frame | Steel Tube Ø 1.0" x 1.2mm (Thickness) |
Cross Brace | 2-Curve Steel Strips Thickness 3.0mm Width 40mm |
Toe Plate | Thickness 3.0mm Height 180mm (W2) Width 360mm |
Wheel | 8" x 1.75" Solid Rubber Wheel with Nylon Bushing |
Wheel Bracket | 3.0mm Welded Steel |
Welded Axle | Ø 12mm x 460mm |
Finishing | Powder Coating System |
Weight | 8.5 Kg |
Capacity | 270Kg |
Overall Size | 1300mm x 545mm x 485mm (L x W1 x H) |
Main Frame | Steel Tube Ø 1.0" x 1.5mm |
Vertical Brace (P-Handle) | Steel Tube Ø 1.0" x 1.5mm |
Cross Brace | 3-Curve Steel Strips Thickness 3.0mm Width 27mm |
Toe Plate | Steel Plate Thickness 3.0mm Height 255mm (W2) Width 360mm |
Wheel | Pneumatic Rubber Wheel 10" x 3.5" (3.5-4) 2-PR with Ball Bearing |
Welded Axle Support | Steel Plate thickness 3.0mm Steel Tube Ø 21.4mm x 2.7mm Welding System |
Welded Axle | Ø 16mm x 490mm |
Finishing | Powder Coating System |
Weight | 11.5 Kg |
Capacity | 180Kg |
Overall Size | 1320mm x 446mm x 428mm (L x W1 x H)/Horizontal 1035mm x 446mm x 953mm (L1 x Wi x LH)/Vertical |
Main Frame | Steel Tube Ø 31.8mm x 1.7mm (Thickness) |
Flow Back Handle | Steel Tube Ø 1.0" x 1.5mm (Thickness) |
Main Frame Cross Bar | Steel Tube Ø 19.1mm x 1.2mm (Thickness) |
Vertical Brace Steel Strip | Thickness 3mm Width 35mm |
Toe Plate | Steel Plate Thickness 3.0mm Height 255mm (W2) Width 360mm |
Wheel | Solid Rubber Wheel 8" x 1.75" with Ball Bearing Swivel Caster Wheel 3" |
Wheel Bracket | U Steel Plate Thickness 2.0mm Welding System |
Welded Axle | Ø 16mm x 465mm |
Finishing | Powder Coating System |
Weight | 14.5 Kg |
